The Fageol 44 cu. in. 35 hp Economy 4-Cycle Outboard

Fageol 44 Economy Outboard AdvertisementThe Fageol 44 Economy Outboard was a front runner in 4-stroke outboard design and was originally produced from 1955 - 1958. The 4-stroke motor history began back in early 40's with Lloyd M Taylor of Taylor Engines who developed the light weight 4-stroke engine. The unique process involved steel stampings which were assembled by copper hydrogen brazing with a finished block weight of 14 pounds.

Paul Klotsch who was an engineer at Crosley Motors Inc. negotiated an exclusive license from Taylor Engines to produce these engines for the Military. They were used to power water pumps, generators and many other applications.

In 1952 the tooling and rights for the 4 cylinder engine were sold to Aero-Jet General with the primary interest of Aero-Jet being the production of engines for the military use. They ventured into the marine market attaching this motor to a Vee-Drive for a complete inboard propulsion system.

Then in 1955 Lou Fageol a well known Boat Racer and president of Fageol Twin Coach Company came up with the idea of producing a 4 cycle outboard motor while recovering from injuries he suffered flipping his boat in a Gold Cup boat race in Seattle. It was a combination of the VIP (Vertical Inboard Power) Crosley 44 cu in motor vertically mounted on an outboard lower unit. It was one of the first 4 cycle outboards to be produced,

In 1956 the Fageol "44" outboard was introduced with the (35 hp) motor mounted on a Scott Atwater lower unit. A Gold Cup "60" (55 hp) was added to the line in 1957. By 1958 the production line included a 35, 40 and 55 horsepower version..

Fageol Products Company was sold to Crofton Manufacturing Company of Los Angeles in 1959 with Crofton continuing replacement parts production along with manufacturing some of the Crofton labeled Fageol outboards.

Fageol - Economy Outboard Manuals

Auto-redirect to download after payment, and link sent to email address you registered with PayPal

1955-1959 Fageol 44 Economy Outboard Literature

Model / Pub. Fageol ID $ USD Manual ID Manual Type
- Fageol -
All Models
44 cu. in.
4-Stroke
$19.98 fageol44esmFageol 44 Inboard Marine Engine Service Manual - Engine -
Service Manual
and Parts List
22 pages pdf
Includes section 8 only which covers just the engine
Model / Pub. Fageol ID $ USD Manual ID Manual Type
FO-4A 306961 $15.98 fageol44omFageol 44 Outboard Owners Manual Owners
Manual
Handbook
FO-4B 308589
FO-4A 306961 $15.98 fageol44rpFageol 44 Outboard Replacement Parts Catalog Economy
Outboard
Parts Catalog
FO-4B 308589
All Models Accessory $10.98 fageol44accFageol 44 Inboard Marine Accessories Catalog Accessories
- Catalog
Pub. 1957 V.I.P. and
Outboard
$10.98 fageol44pplFageol 44 VIP and Outboard Parts Price List Parts Price List
62 pages pdf
All Models Vee-Drive
+ V.I.P. +
Outboard
$10.98 fageol44sbFageol 44 All Units Service Bulletins Service Bulletins
Collection #1-36
All Fageol 44's
All Models Vee-Drive
+ V.I.P. +
Outboard
$5.98 fageol44dsbFageol 44 All Units Dealer Sales Bulletins Dealer Sales
Bulletins +
Promotions

Fageol Outboard Design Evolution

Fageol 44 Economy OutboardThe Fageol outboard version was the first large 4-cycle outboard commercially available in the United States.

The block was vertically mounted to an outboard lower unit to produce a light weight economical competitor to gas-thirsty 2-cycle outboard dominating the industry.

Fageol offered single carburetor, dual carburetor and supercharger options increasing output up to 45 HP.

The outboard design went on to be acquired by two more companies who each produced outboards with upgrades and modifications as the Homelite 55hp, and Fisher Pierce Bearcat 55hp outboard motors.
